[AP] Implement pcc compile engine frontend of trivial fusion. #72640

lixinqi · 2025-05-09T08:38:05Z

PR Category

CINN

PR Types

New features

Description

pcard-76996

动机

当前pcc受制于组合算子拆解和CINN融合前端，用户不能直接操控融合算子范围。
本次pr为pcc.compile切换了新的编译引擎，该引擎直接按用户意图融合代码（相信程序员），不依赖组合算子拆解和CINN融合前端，然后直接进行apass处理。

示例用法

pcc.fuse.by_register

import paddle.incubate.cc as pcc
import paddle.incubate.cc.typing as pct
import paddle

N = pct.DimVar(1024)
K = pct.DimVar(256)
M = pct.DimVar(256)
DType = pct.DTypeVar("T","float32")

def foo(
    x: pct.Tensor([N, K], DType),
    w: pct.Tensor([K, M], DType)
):

    y = paddle.matmul(x, w)
    with pcc.fuse.by_register():
        tmp = paddle.sin(y)
        return tmp, paddle.cos(y)[256:]

fused_foo = pcc.compile(
    foo,
    ap_path=dir_to_your_axpr_code,
)

示例日志

E0429 08:50:43.123240 111481 add_pcc_pass.cc:138] 0) after ApplyApFacadePass():
{
    (%0) = "pd_op.data" () {dtype:float32,name:"x",place:Place(undefined:0),shape:[1024,256],stop_gradient:[false]} : () -> tensor<1024x256xf32>
    (%1) = "pd_op.data" () {dtype:float32,name:"w",place:Place(undefined:0),shape:[256,256],stop_gradient:[false]} : () -> tensor<256x256xf32>
    (%2) = "pd_op.matmul" (%0, %1) {stop_gradient:[false],transpose_x:false,transpose_y:false} : (tensor<1024x256xf32>, tensor<256x256xf32>) -> tensor<1024x256xf32>
    (%3) = "pd_op.ap_trivial_fusion_begin" (<<NULL VALUE>>) {stop_gradient:[true]} : (<<NULL TYPE>>) -> tensor<b>
    (%4) = "pd_op.sin" (%2) {stop_gradient:[false]} : (tensor<1024x256xf32>) -> tensor<1024x256xf32>
    (%5) = "pd_op.cos" (%2) {stop_gradient:[false]} : (tensor<1024x256xf32>) -> tensor<1024x256xf32>
    (%6) = "pd_op.full_int_array" () {dtype:int64,place:Place(cpu),stop_gradient:[true],value:[256]} : () -> tensor<1xi64>
    (%7) = "pd_op.full_int_array" () {dtype:int64,place:Place(cpu),stop_gradient:[true],value:[2147483647]} : () -> tensor<1xi64>
    (%8) = "pd_op.slice" (%5, %6, %7) {axes:[0],decrease_axis:[],infer_flags:[1],stop_gradient:[false]} : (tensor<1024x256xf32>, tensor<1xi64>, tensor<1xi64>) -> tensor<768x256xf32>
    (%9) = "pd_op.ap_trivial_fusion_end" (<<NULL VALUE>>) {stop_gradient:[true]} : (<<NULL TYPE>>) -> tensor<b>
    () = "builtin.shadow_output" (%4) {output_name:"output_0"} : (tensor<1024x256xf32>) ->
    () = "builtin.shadow_output" (%8) {output_name:"output_1"} : (tensor<768x256xf32>) ->
}
E0429 08:50:43.123449 111481 add_pcc_pass.cc:138] 1) after ApplyFuseApTrivialPass():
{
    (%0) = "pd_op.data" () {dtype:float32,name:"x",place:Place(undefined:0),shape:[1024,256],stop_gradient:[false]} : () -> tensor<1024x256xf32>
    (%1) = "pd_op.data" () {dtype:float32,name:"w",place:Place(undefined:0),shape:[256,256],stop_gradient:[false]} : () -> tensor<256x256xf32>
    (%2) = "pd_op.matmul" (%0, %1) {stop_gradient:[false],transpose_x:false,transpose_y:false} : (tensor<1024x256xf32>, tensor<256x256xf32>) -> tensor<1024x256xf32>
    (%3, %4) = "cinn_op.fusion" () -> tensor<1024x256xf32>, tensor<768x256xf32> {
        (%5) = "pd_op.sin" (%2) {stop_gradient:[false]} : (tensor<1024x256xf32>) -> tensor<1024x256xf32>
        (%6) = "pd_op.cos" (%2) {stop_gradient:[false]} : (tensor<1024x256xf32>) -> tensor<1024x256xf32>
        (%7) = "pd_op.full_int_array" () {dtype:int64,place:Place(cpu),stop_gradient:[true],value:[256]} : () -> tensor<1xi64>
        (%8) = "pd_op.full_int_array" () {dtype:int64,place:Place(cpu),stop_gradient:[true],value:[2147483647]} : () -> tensor<1xi64>
        (%9) = "pd_op.slice" (%6, %7, %8) {axes:[0],decrease_axis:[],infer_flags:[1],stop_gradient:[false]} : (tensor<1024x256xf32>, tensor<1xi64>, tensor<1xi64>) -> tensor<768x256xf32>
        () = "cf.yield" (%5, %9) {} : (tensor<1024x256xf32>, tensor<768x256xf32>) ->
    }
    () = "builtin.shadow_output" (%3) {output_name:"output_0"} : (tensor<1024x256xf32>) ->
    () = "builtin.shadow_output" (%4) {output_name:"output_1"} : (tensor<768x256xf32>) ->
}
E0429 08:50:43.123849 111481 add_pcc_pass.cc:138] 2) after ApplyGenerateShapePass():
{
    (%0) = "pd_op.data" () {dtype:float32,name:"x",place:Place(undefined:0),shape:[1024,256],stop_gradient:[false]} : () -> tensor<1024x256xf32>
    (%1) = "pd_op.data" () {dtype:float32,name:"w",place:Place(undefined:0),shape:[256,256],stop_gradient:[false]} : () -> tensor<256x256xf32>
    (%2) = "pd_op.matmul" (%0, %1) {stop_gradient:[false],transpose_x:false,transpose_y:false} : (tensor<1024x256xf32>, tensor<256x256xf32>) -> tensor<1024x256xf32>
    (%3, %4) = "cinn_op.fusion" () -> tensor<1024x256xf32>, tensor<768x256xf32> {
        (%5) = "pd_op.sin" (%2) {stop_gradient:[false]} : (tensor<1024x256xf32>) -> tensor<1024x256xf32>
        (%6) = "pd_op.cos" (%2) {stop_gradient:[false]} : (tensor<1024x256xf32>) -> tensor<1024x256xf32>
        (%7) = "cinn_op.generate_shape" () {output_dim_exprs:[256],stop_gradient:[true],symbol_bindings:[]} : () -> tensor<1xi64>
        (%8) = "cinn_op.generate_shape" () {output_dim_exprs:[2147483647],stop_gradient:[true],symbol_bindings:[]} : () -> tensor<1xi64>
        (%9) = "pd_op.slice" (%6, %7, %8) {axes:[0],decrease_axis:[],infer_flags:[1],stop_gradient:[false]} : (tensor<1024x256xf32>, tensor<1xi64>, tensor<1xi64>) -> tensor<768x256xf32>
        () = "cf.yield" (%5, %9) {} : (tensor<1024x256xf32>, tensor<768x256xf32>) ->
    }
    () = "builtin.shadow_output" (%3) {output_name:"output_0"} : (tensor<1024x256xf32>) ->
    () = "builtin.shadow_output" (%4) {output_name:"output_1"} : (tensor<768x256xf32>) ->
}
E0429 08:50:43.123997 111481 ap_generic_drr_pass.cc:3313]
Traceback (most recent call last):
  File "/root/workspace/Paddle/paddle/ap/src/paddle/pass/ap_generic_drr_pass.cc", line 3304, in operator()
    ApRegistryHelper{}.SingletonRegistry()
  File "/root/workspace/Paddle/paddle/ap/src/paddle/pass/ap_registry_helper.cc", line 30, in operator()
    RegistrySingleton::Singleton()
  File "/root/workspace/Paddle/paddle/ap/include/registry/registry_singleton.h", line 26, in operator()
    MutOptSingleton()->has_value()

NotImplementedError: Registry singleton not initialized.
E0429 08:50:43.124019 111481 ap_generic_drr_pass.cc:3313]
Traceback (most recent call last):
  File "/root/workspace/Paddle/paddle/ap/src/paddle/pass/ap_generic_drr_pass.cc", line 3304, in operator()
    ApRegistryHelper{}.SingletonRegistry()
  File "/root/workspace/Paddle/paddle/ap/src/paddle/pass/ap_registry_helper.cc", line 30, in operator()
    RegistrySingleton::Singleton()
  File "/root/workspace/Paddle/paddle/ap/include/registry/registry_singleton.h", line 26, in operator()
    MutOptSingleton()->has_value()

NotImplementedError: Registry singleton not initialized.
E0429 08:50:43.124032 111481 add_pcc_pass.cc:138] 3) after ApplyApGenericDrrPass():
{
    (%0) = "pd_op.data" () {dtype:float32,name:"x",place:Place(undefined:0),shape:[1024,256],stop_gradient:[false]} : () -> tensor<1024x256xf32>
    (%1) = "pd_op.data" () {dtype:float32,name:"w",place:Place(undefined:0),shape:[256,256],stop_gradient:[false]} : () -> tensor<256x256xf32>
    (%2) = "pd_op.matmul" (%0, %1) {stop_gradient:[false],transpose_x:false,transpose_y:false} : (tensor<1024x256xf32>, tensor<256x256xf32>) -> tensor<1024x256xf32>
    (%3, %4) = "cinn_op.fusion" () -> tensor<1024x256xf32>, tensor<768x256xf32> {
        (%5) = "pd_op.sin" (%2) {stop_gradient:[false]} : (tensor<1024x256xf32>) -> tensor<1024x256xf32>
        (%6) = "pd_op.cos" (%2) {stop_gradient:[false]} : (tensor<1024x256xf32>) -> tensor<1024x256xf32>
        (%7) = "cinn_op.generate_shape" () {output_dim_exprs:[256],stop_gradient:[true],symbol_bindings:[]} : () -> tensor<1xi64>
        (%8) = "cinn_op.generate_shape" () {output_dim_exprs:[2147483647],stop_gradient:[true],symbol_bindings:[]} : () -> tensor<1xi64>
        (%9) = "pd_op.slice" (%6, %7, %8) {axes:[0],decrease_axis:[],infer_flags:[1],stop_gradient:[false]} : (tensor<1024x256xf32>, tensor<1xi64>, tensor<1xi64>) -> tensor<768x256xf32>
        () = "cf.yield" (%5, %9) {} : (tensor<1024x256xf32>, tensor<768x256xf32>) ->
    }
    () = "builtin.shadow_output" (%3) {output_name:"output_0"} : (tensor<1024x256xf32>) ->
    () = "builtin.shadow_output" (%4) {output_name:"output_1"} : (tensor<768x256xf32>) ->
}
E0429 08:50:43.124235 111481 add_pcc_pass.cc:138] 4) after ApplyFallbackToPhiPass():
{
    (%0) = "pd_op.data" () {dtype:float32,name:"x",place:Place(undefined:0),shape:[1024,256],stop_gradient:[false]} : () -> tensor<1024x256xf32>
    (%1) = "pd_op.data" () {dtype:float32,name:"w",place:Place(undefined:0),shape:[256,256],stop_gradient:[false]} : () -> tensor<256x256xf32>
    (%2) = "pd_op.matmul" (%0, %1) {stop_gradient:[false],transpose_x:false,transpose_y:false} : (tensor<1024x256xf32>, tensor<256x256xf32>) -> tensor<1024x256xf32>
    (%3) = "pd_op.sin" (%2) {stop_gradient:[false]} : (tensor<1024x256xf32>) -> tensor<1024x256xf32>
    (%4) = "pd_op.cos" (%2) {stop_gradient:[false]} : (tensor<1024x256xf32>) -> tensor<1024x256xf32>
    (%5) = "pd_op.full_int_array" () {dtype:int64,place:Place(cpu),stop_gradient:[true],value:[256]} : () -> tensor<1xi64>
    (%6) = "pd_op.full_int_array" () {dtype:int64,place:Place(cpu),stop_gradient:[true],value:[2147483647]} : () -> tensor<1xi64>
    (%7) = "pd_op.slice" (%4, %5, %6) {axes:[0],decrease_axis:[],infer_flags:[1],stop_gradient:[false]} : (tensor<1024x256xf32>, tensor<1xi64>, tensor<1xi64>) -> tensor<768x256xf32>
    () = "builtin.shadow_output" (%3) {output_name:"output_0"} : (tensor<1024x256xf32>) ->
    () = "builtin.shadow_output" (%7) {output_name:"output_1"} : (tensor<768x256xf32>) ->
}

PCC编译引擎总共分如下几个步骤：

ApplyApFacadePass.将pd_op.ap_facade替换成ap_op.facade
ApplyFuseApTrivialPass. 将介于pd_op.ap_trivial_fusion_begin和pd_op.ap_trivial_fusion_end之间的op融合成cinn_op.fusion
ApplyGenerateShapePass. 将用于处理动态形状的算子聚合成cinn_op.generate_shape算子
ApplyApGenericDrrPass. 应用ap_path参数指定的系统的apass。上述日志此步骤报错，因为本示例程序没有配apass。
ApplyFallbackToPhiPass. 将未成功编译的cinn_op.fusion子图降级到phi

…p is enabled.

…interpret_cast to avoid strict-aliasing.

…atement added by previous commit.

…addle#70376.

…zd5568.

…compile.

Fix the mismatched output numerical order issue

paddle-bot · 2025-05-09T08:38:11Z

你的PR提交成功，感谢你对开源项目的贡献!
请关注后续CI自动化测试结果，详情请参考Paddle-CI手册。
Your PR has been submitted. Thanks for your contribution!
Please wait for the result of CI firstly. See Paddle CI Manual for details.

XiaoguangHu01

LGTM

SigureMo

LGTMeow

SigureMo · 2025-05-13T04:36:37Z

python/paddle/jit/dy2static/pir_partial_program.py

                    paddle.base.libpaddle.pir.bind_symbolic_constraints(
                        forward_program, self._constraints
                    )
                    paddle.base.libpaddle.pir.apply_cinn_pass(forward_program)
-
+                elif self._backend.is_pcc():


pcc backend 没有调用 apply_general_passes 是因为 CSE 有问题是么？如果是这样的话我后面可以看看

多谢啦。pcc backend还需要通过实验验证需要加哪些Pass，目前功能尚不完整。CSE暂时没发现问题。
